Altrad Belle DC 300E+ - Technical Data; General Data; Battery; Battery Charger

8
Technical Data
GB
* Weight does not include battery.
Model DC 300E+
Voltage (v) 82
No Load Speed (m/s) 82
Blade Outside Diameter (mm) 300
Blade Bore Diameter (mm) 20 or 25.4
Blade Tightening Torque (Nm) 25
Max. Depth of Cut (mm) 112
Max. Water Supply Pressure (bar) 6
*Weight (Kg) 5.7
Sound Power Level (dB L
WA
) 114
3 Axis Vibration - Main Handle (m/sec
2
) < 2.5
3 Axis Vibration - Auxiliary Handle (m/sec
2
) 2.6
Model 8Ah Battery
Model Code OPM/14/FIO
Battery Type Li-Ion
Weight (kg) 3.9
Dimensions L x W x H (mm) 120 x 90 x 240
Max. Voltage (v) 82
Nominal Voltage (v) 72
Energy Rating (Wh) 580
Energy Capacity (Ah) 8
80% Charge Time (Mins) 48
100% Charge Time (Mins) 65
Model Battery Charger
Model Code OPM/16/FIO
Dimensions LxWxH (mm) 230 x 170 x 170
Weight (kg) 2.0
Input Voltage AC (v) 230v
Input Frequency (Hz) 50 / 60
Output voltage DC (v) 82
Output current (A) 8
GENERAL DATA
BATTERY
BATTERY CHARGER
