12.3 READ ONLY STATUS REGISTERS
ADDRESS FUNCTION
30001 Input Bit Mirror 10016–10001
30002 Input Bit Mirror 10032–10017
30003 Input Bit Mirror 10048–10033
30004 Input Bit Mirror 10064–10049
30005 RPM
30006 Timing xxx.xDEG signed
30007 Switch Position 1–8
30008 Current Loop Input xx.xmA
30009 Disk Observed X+1
30010 Insertion Retard xxx.xDeg
30011 Switch Retard xxx.xDeg
30012 Loop Retard xxx.xDeg
30013 RPM Retard xxx.xDeg
30014 Total Retard xxx.xDeg
30015 Cycle Counter HI
30016 Cycle Counter LO
30017 Supply Voltage xx.xVolts
30018 Spark Ref. Num. Output A
30019 Spark Ref. Num. Output B
30020 Spark Ref. Num. Output C
30021 Spark Ref. Num. Output D
30022 Spark Ref. Num. Output E
30023 Spark Ref. Num. Output F
30024 Spark Ref. Num. Output K
30025 Spark Ref. Num. Output L
30026 Spark Ref. Num. Output M
30027 Spark Ref. Num. Output N
30028 Spark Ref. Num. Output P
30029 Spark Ref. Num. Output R
30030 Spark Ref. Num. Output S
30031 Spark Ref. Num. Output T
30032 Spark Ref. Num. Output U
30033 Spark Ref. Num. Output V
30034 Purge Delay Index Down Counter
30035 Distributor MUX code 0–15
30036 KEYCOMMAND
30037 Period Predivider
30038 Period MS16BITS
30039 Period LS16BITS
30040 FireStat:DelayStat
