- 4 - AL175UL
NO RESET
SWITCH
FACP
MAG LOCK
ACCESS
CONTROL
DEVICE
LOCK +
STRIKE +
TRG2
TRG1
C
NO
NC
COM --
FACP
MAG LOCK
MAG LOCK
ACCESS CONTROL
DEVICE
LOCK +
STRIKE +
TRG2
TRG1
COM --
C
NO
NC
TRG1
TRG2
FACP
MAG LOCK
DOOR
STRIKE
PROX/CARD
READER
ACCESS
CONTROL
DEVICE
LOCK +
STRIKE +
TRG2
TRG1
AUX +
AUX --
COM --
FACP
MAG LOCK
ACCESS
CONTROL
DEVICE
AUX +
FACP +
AUX --
Fig. 5 Latching fire alarm tie-in with manual reset:
Fig. 3 Typical dual mag lock installation with fire alarm
tie-in using trigger controlled outputs:
Fig. 6 Multiple AL175UL(X) power supply
connections:
Fig. 2 Typical single mag lock or door strike installation
with fire alarm tie-in using trigger controlled output:
Typical Application Diagrams:
Fig. 4 Typical mag lock with fire alarm tie-in using
aux output installation:
Altronix is not responsible for any typographical errors.
140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056
website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty | Made in U.S.A.
IIAL175UL Rev. 081601 C24P
