Altronix PT724A Series User Manual

- 5 -
C. Setting Block Events (weekly repeat):
Depress SET until ENTER to
SET BK
Depress ENTER BK=SA/SU
TIME=DS
Flashing cursor will appear at the location of the first day of the week desired. Depress UP and DWN to
select day. Depress ENTER to confirm selection, then cursor will appear at the location of the last day of the
week desired. Depress UP and DWN to select day. Depress ENTER to confirm selection. Depress ENTER
again to escape.
D. Setting Holiday Events:
Depress SETuntil ENTER to
SET EVENT
Depress ENTER #01 ON
HL 00:00
Next select HL to indicate as holiday event and time by scrolling using UP and DWN push buttons and
depress ENTER to accept.
You may continue to program more holiday events by repeating the previous steps or exit programming by
depressing SET.
E. Setting Holiday Dates:
It is now necessary to assign these holiday events specific calendar dates which they are to occur.
To select Holiday events depress SET until
ENTER to
SET HOL
Depress ENTER #01 HOL
SU 00:00
Note: Holiday events will override all regularly programmed events.
F. Delete/Disable Events or Edit Events:
Previously programmed regularly scheduled and/or holiday events may be deleted/disabled without having
to erase all events.
Depress SET until
ENTER to
SET EVENT
Depress ENTER #01 ON
TU 00:00
Now scroll using UP and DWN push buttons to the event you wish to delete, depress ENTER to move
flashing cursor under relay option then depress UP and DWN push buttons until DIS is displayed, depress
ENTER to confirm.
appears in display.
will appear in display.
appears in display.
will appear in display.
>
appears in display.
will appear in display.
>
will appear in display.
>
appears in display.
