High Gain antenna - RE046
• Best performance
• Offers optimal cellular performance
Other cellular antenna options
• Nearson T6155AM-LTE-S
• Taoglas TG.30.8113
• Laird DBA6927C1-FSMAM
Antenna Removal and Installation
1. Pull up gently on the internal antenna’s connector to release it from the cellular module.
2. Remove the internal antenna.
3. Break out the plastic plug in hole at top of enclosure.
4. Install the large (SMA) end of the supplied cable in hole in top of enclosure, and secure
with supplied nut.
5. Snap the small end of the supplied cable into the circuit board.
6. Thread the high gain antenna to the SMA connector at top of enclosure.
