IPB-5000B
9. Timing Chart
9-11
1) In the case of OFF or BI-DIRECTION at COMM CONTROL,
Display Screen
CALCULATION MODE
NORMAL FAST
SCHEDULE 360 ms
310 ms
MONITOR 205 ms 155 ms
COMPARATOR 380 ms 330 ms
ENVELOPE 515 ms 465 ms
PRECHECK 220 ms 170 ms
CONTROL 215 ms 165 ms
STATUS 205 ms 155 ms
2) In the case of DATA OUTPUT at COMM CONTROL,
COMM
SPEED
Display Screen
CALCULATION MODE
NORMAL FAST
9600bps
SCHEDULE 485 ms
435 ms
MONITOR 330 ms 280 ms
COMPARATOR 505 ms 455 ms
ENVELOPE 640 ms 590 ms
PRECHECK 345 ms 295 ms
CONTROL 340 ms 290 ms
STATUS 330 ms 280 ms
19200bps
SCHEDULE 430 ms 380 ms
MONITOR 275 ms 225 ms
COMPARATOR 450 ms 400 ms
ENVELOPE 585 ms 535 ms
PRECHECK 290 ms 240 ms
CONTROL 285 ms 235 ms
STATUS 275 ms 225 ms
38400bps
SCHEDULE 400 ms 350 ms
MONITOR 245 ms 195 ms
COMPARATOR 420 ms 370 ms
ENVELOPE 555 ms 505 ms
PRECHECK 260 ms 210 ms
CONTROL 255 ms 205 ms
STATUS 245 ms 195 ms
 1-2 Setting
As same as in  1-5 Setting, weld current is supplied on the consecutive 2
SCHEDULE No.’s in turn.
Weld current is supplied through the transformer selected at Transformer No.
(TR#) in each SCHEDULE Screen.
Note)
The values at the
tables show maximum
ones.
Note)
The values at
the tables show
maximum ones.
