APPENDIX E: EtherNet/IP
TM
COMMUNICATIONS
IS-300CR INVERTER POWER SUPPLY
990-418 E-43
Bus Controller I/O Wiring Diagrams
XC20BC0088 – Controller Module
X20 PS9400 – I/O Supply Module
LED status indicators
Network address switches
Ethernet/IP connection with
2x RJ45 ports for easy wiring
Terminal block for bus controller
and I/O supply
