Service
This manual is to be used by qualified appliance technicians only.
Amana does not assume any responsibility for property damage or
personal injury for improper service procedures done by an
RS1200004
Revision 0
May 2001
18, 21, & 22 Cu. Ft.
Bottom Mount Refrigerators
This Base Manual covers 18, 21, and
22 Cu. Ft. Bottom Mount Refrigerators.
Refer to individual Technical Sheet
for specific information on models.

Table of Contents

Questions and Answers

  • J
    Jennifer CoxAug 21, 2025
    What to do if my Amana 18 Cu. Ft and freezer are too warm?
    • J
      Jacqueline BrooksAug 21, 2025
      If both the freezer and refrigerator sections of your Amana Refrigerator are too warm, start by checking if the temperature controls are set too warm and reset them if needed. A poor door seal can also cause this issue, so level the cabinet, adjust the hinges, and replace the gasket if necessary. Make sure the condenser and grille are clean and not obstructed. If the control is faulty, test it and replace it if it has failed. A refrigerant shortage or restriction could also be the problem; check for leaks or restrictions, then repair, evacuate, and recharge the system.
  • A
    andersonderekAug 25, 2025
    How to fix a noisy Amana Refrigerator?
    • K
      Karen RogersAug 26, 2025
      If your Amana Refrigerator is operating noisily, several factors could be the cause. Check if the flooring is loose or not firm, and repair or brace the floor if needed. Ensure the cabinet is level. Adjust any tubing that's in contact with the cabinet, other tubing, or other metal. If the drip pan is vibrating, adjust it. Make sure the fan is properly aligned and that all attaching hardware and brackets are tight and not worn; tighten or replace them as necessary. Inspect the fan motor for loss of lubricant or worn bearings and replace it if necessary. Tighten any loose mounting hardware and replace worn or missing compressor mounting grommets. Finally, inspect the unit for any free or loose parts or missing screws and repair as required.
  • R
    Rebecca StewartAug 28, 2025
    Why is my Amana 18 Cu. Ft Refrigerator section too cold?
    • Q
      qstewartAug 28, 2025
      If the refrigerator section of your Amana Refrigerator is too cold, the refrigerator temperature control might be set too cold; adjust it accordingly. Also, check the airflow to ensure it is properly adjusted.
  • M
    Mary TurnerSep 1, 2025
    What causes an Amana 18 Cu. Ft freezer section to be too cold?
    • C
      courtney97Sep 1, 2025
      If the freezer section of your Amana Refrigerator is too cold, the freezer temperature control may be set too cold; adjust it. Also, a faulty control could be the cause; test it and replace it if it has failed. If the cold control capillary is not properly clamped to the evaporator, reposition the clamp and tighten it.
  • C
    carrmarySep 8, 2025
    What to do if Amana 18 Cu. Ft Refrigerator runs continuously and is too cold?
    • R
      Richard ThomasSep 9, 2025
      If your Amana Refrigerator runs continuously and the temperature is too cold, the defrost thermostat may be faulty. Check the thermostat and replace it if necessary.
  • K
    Kevin BergNov 12, 2025
    Why does my Amana 18 Cu. Ft Refrigerator unit run continuously?
    • V
      Vanessa PatelNov 12, 2025
      If your Amana Refrigerator runs continuously, consider these potential causes: the temperature control might be set too cold, so adjust it. A dirty condenser or obstructed grille can also cause this issue, so check and clean them. A poor door seal could be the culprit; level the cabinet, adjust the hinges, and replace the gasket if needed. Ensure the interior light isn't staying on, and if it is, check the switch and replace it if necessary. Check the condenser fan or evaporator fan and their wiring, replacing if necessary. A faulty control could also be the reason, so test it and replace it if it has failed. Other potential issues include a refrigerant shortage or restriction, refrigerant overcharge, or air in the system. Check for leaks or restrictions, overcharge, or low side leaks; rep...
  • C
    Carolyn WhitneyNov 16, 2025
    Why is my Amana Refrigerator section too warm?
    • P
      paulajoyceNov 16, 2025
      If the refrigerator section of your Amana Refrigerator is too warm, several factors could be the cause. Avoid excessive door opening, overloading shelves, and placing warm or hot foods in the cabinet. Ensure the cold control isn't set too warm; if so, adjust it to a colder setting. Check the door seal for any issues; level the cabinet, adjust the hinges, or replace the gasket if necessary. Also, make sure the refrigerator airflow is properly adjusted by checking that the damper opens when the door is open; replace it if it's faulty and turn the control knob to a colder position. See if the interior light remains on, and if it does, check and replace the switch if needed. Finally, inspect the condenser fan or evaporator fan and their wiring, replacing if necessary. In some cases, a faulty c...

Summary

Service and Product Overview

Product Design

Explains the fundamental design of the refrigerator's systems.

Refrigeration System

Details the operational principles of the cooling cycle.

Temperature Controls

Describes how to set and manage refrigerator and freezer temperatures.

Defrost System

Describes the automatic defrost process and components.

Component Testing Procedures

Compressor Testing

Procedures for testing compressor functionality, windings, and overload.

Electrical Component Testing

Steps for checking capacitor, relay, and other electrical parts.

Refrigerant System Components Testing

Testing procedures for the drier, timer, and thermostat.

Evaporator and Damper Control Testing

Procedures for testing evaporator and air damper components.

Service Procedures and System Handling

Service Equipment Requirements

Lists essential tools and equipment for servicing.

Drier Replacement and Refrigerant Handling

Steps for replacing the drier and precautions for refrigerants.

Evacuation, Charging, and Brazing

Procedures for system evacuation, charging, and brazing techniques.

HFC134 a Service Information

Important considerations for servicing with HFC134a refrigerant.

Replacement Service Compressor

Instructions for installing a new compressor.

System Flow, Airflow, and Troubleshooting

Refrigerant Flow Diagram

Visual representation of refrigerant path through the system.

Cabinet Air Flow Diagrams

Illustrates air circulation within refrigerator compartments.

Troubleshooting Chart

Lists symptoms, causes, and corrective actions for common issues.

System Diagnosis Guide

Analyzes system performance based on pressure and temperature variations.

Disassembly and Component Removal

Unit Unpacking and Door Removal

Initial unpacking and procedures for removing doors.

Refrigerator Compartment Disassembly

Steps for removing components from the fresh food section.

Freezer Compartment Disassembly

Steps for removing components from the freezer section.

Major Component Removal

Procedures for removing the evaporator and compressor.

Ice Maker Service and Troubleshooting

Ice Maker Operation and Testing

Explains ice maker function, specifications, and testing procedures.

Ice Maker Troubleshooting Chart

Common ice maker issues, causes, and solutions.

Installation and Setup

Installation Instructions Overview

General guidance for installing the refrigerator.

Door Handling and Reversal

Procedures for removing, reversing, and rehanging doors.

Water Supply and Final Steps

Connecting water supply and completing installation.

Controls, Features, and Maintenance

Refrigerator Controls and Features

Location and adjustment of temperature and interior feature controls.

Deepfreeze Features

Details on ice maker, shelves, and storage bins.

Care and Cleaning Procedures

Guidelines for maintaining refrigerator cleanliness and appearance.

Before Calling For Service

Troubleshooting common problems before seeking professional help.

Warranty Information

Warranty Coverage and Limitations

Details on product warranty, coverage, and limitations.

Owners Responsibilities

Owner's duties regarding maintenance and service access.
