Amana Asure ASH13 - Page 3

Specifi cation Sheet
SS-ASH13 www.amana-hac.com 3
SPECIFICATIONS
ASH13-
0181A
ASH13-
0241A
ASH13-
0301A
ASH13-
0361A
ASH13-
0421A
ASH13-
0481A
ASH13-
0601A
Capacities and Ratings
Nominal Cooling (BTU/h) 18,000 23,600 28,000 35,000 40,000 45,000 55,500
Nominal Heating (BTU/h) 17,400 23,000 27,000 34,000 39,500 43,000 55,500
Compressor
RLA 9 10.9 12.2 13.4 16.5 17.9 24.3
LRA 41 54 63 73 95 104 148
Condenser Fan Motor
Horsepower 1/6 1/6 1/6 1/4 1/4 1/4 1/6
FLA 0.9 0.9 0.9 1.5 1.5 1.5 1.1
Refrigerant Lines
Liquid Valve Size (“O.D.)* 3/8” 3/8” 3/8” 3/8” 3/8” 3/8” 3/8”
Suction Valve Size (“O.D.)* 3/4” 3/4” 3/4” 7/8” 7/8” 7/8” 7/8”
Valve Connection Type Sweat Sweat Sweat Sweat Sweat Sweat Sweat
Refrigerant Charge 115 117 153 188 213 223 233
Shipped with Orifi ce Size 0.052 0.062 0.065 0.073 0.082 0.084 0.093
Electrical Data
Voltage 208/230 208/230 208/230 208/230 208/230 208/230 208/230
Hz/Phase 60/1 60/1 60/1 60/1 60/1 60/1 60/1
Minimum Circuit Ampacity
1
12.1 14.5 16.1 18.3 22.2 23.9 31.5
Maximum Overcurrent Device
2
20 20 20 30 30 40 50
Min / Max Volts 197/253 197/253 197/253 197/253 197/253 197/253 197/253
Power Supply Conduit Size 1/2” or 3/4” 1/2” or 3/4” 1/2” or 3/4” 1/2” or 3/4” 1/2” or 3/4” 1/2” or 3/4” 1/2” or 3/4”
Ship Weight (lbs) 175 190 240 260 260 275 325
* Line size up to 35’ in equivalent line length
1) Wire size should be determined in accordance with National Electrical Codes; extensive wire runs will require larger wire sizes
2) May use fuses or HACR-type circuit breakers of the same size as noted
