Amana AVXC20 Series User Manual

6
AVPVC**14
*Revision level that may or may not be designated.
NOTE: Airflow selection should meet the minimum requirements as mentioned in the air handler installation instructions.
NOTE: Airflow data shown applies to the electric heat only in either legacy mode or communicating mode operation.
* Within thermostat user menu, CTK04 communicating thermostat will display 20 kW for OFF-OFF-ON dip switch selection and
21 kW for OFF- OFF-OFF dip switch selection.
NR- Not rated
+
For match up with a 2 ton outdoor unit: Heater kit application shall not exceed 10 kW.
Airflow for 5 kW up to 10 kW heater kits shall be set to 850 cfm speed tap of ON-ON-ON.
++
For match up with a 3 ton outdoor unit: Heater kit application shall not exceed 15 kW.
Airflow for 5 kW up to 15 kW heater kits shall be set to 1300 cfm speed tap of ON-OFF-ON.
Airflow for 5 kW up to 20 kW heater kits shall be set to 1500 cfm speed tap of ON-OFF-OFF
** 3 kW heater kit is not applicable for this indoor application.
ACCESSORIES
AVXC20***1**
Htr kW 9 10 11 AVPVC24C14* AVPVC36D14A+ AVPVC48D14*++ AVPVC60D14++
3 ON ON ON 730 850** NR NR
5 ON ON OFF 780 1250 1250 1250
6 ON OFF ON 850 1300 1300 1300
8 ON OFF OFF 950 1500 1500 1500
10 OFF ON ON 1025 1550 1550 1550
15 OFF ON OFF NR 1720 1720 1780
19* NR NR NR NR
20 NR 1800 1815 1850
21 or 25* OFF OFF OFF NR NR 1850 1850
OFF OFF ON
ELECTRIC HEAT AIRFLOW TABLE
Models
HKSX03XC HKSX05XC HKSX06XC HKSX08XC HKSX10XC HKSC05XC HKSC08XC HKSC10XC
HKSC15XA
HKSC15XB HKSC15XF
HKSC19CA
HKSC19CB
HKSC20DA HKSC20DB
HKSC20XF
HKSC25DC
AVPVC24C14* XXXXXXXX
AVPVC36D14* XXXXXXXXXX XXX
AVPVC48D14* XXXXXXXXXX XXXX
AVPVC60D14* XXXXXXXXXX XXXX
Model Name TXV-Kit
AVXC200241** TXV-V24
AVXC200361** TXV-V36
AVXC200481** TXV-V48
AVXC200601** TXV-V60
