General Information
10 16026086 ©2005 Maytag Services
Microwave Oven Description
A—Window door screen
B—Spatter shields
C—Control panel (Electronic or Dial)
D—Door open button
E—Safety door lock system
230 V / 13 AMP
Receptacle
Plug
Equipment requires a
230 VAC, 50 Hz, 13 amp power supply
Receptacle
Plug
230 V / 16 AMP
Equipment requires a
230 VAC, 50 Hz, 16 amp power supply
Do not use a extension cord. If the product power cord is too short, have a qualified electrician install a
three-prong receptacle. This unit should be plug into a separate dedicated 230 VAC / 50 Hz power supply. If other
equipment is on the same circuit, an increase in cooking times may be required and fuse can be blown.
D
E
A
B
C
