11
Dial Operation
Dial option is available on some models only.
The switching operation of this
microwave oven can cause voltage
fluctuations on the supply line. The
operation of this oven under unfavorable
voltage supply conditions can have
adverse effects. This device is intended
for the connection to a power supply
system with a maximum permissible
system impedance Zmax of 0.2 Ohms
at the interface point of the user’s
supply. The user has to ensure that
this device is connected only to a
power supply system which fulfills the
requirement above. If necessary, the
user can ask the public power supply
company for the system impedance at
the interface point.
Oven Wall Clearances
A—For North American (UL/CSA) models,
allow at least 2” (5.1 cm) of clearance
around top of oven. For International (50 Hz)
models, allow at least 12” (30 cm) of
clearance around top of oven. Proper air
flow around oven cools electrical
components. With restricted air flow, oven
may not operate properly and life of
electrical parts is reduced.
B—Allow at least 2” (5.1 cm) between air
discharge on back of oven and back wall.
C—Allow at least 2” (5.1 cm) of clearance
around sides of oven.
No metal pans
DO NOT power spray
So...how do I use it? (Mechanical Dial)
Heating
1. Open oven door, place food in oven, and close oven door.
2. Turn time entry knob clockwise to desired time.
• Cooking time can be set up to 6 minutes.
• Oven begins operation and time counts down.
3. When cooking time has elapsed, microwave energy stops and oven
signal sounds.
Interrupting Operation
Open oven door to interrupt operation or turn time entry knob counterclockwise
to “0”.
To resume microwave oven operation, close door and turn knob.
Changing Time and Canceling Mistakes
Heating time can be changed at any time while the oven is operating. Turn
knob to desired new setting. To set cooking time to zero, turn knob
counterclockwise to “0”.
C
A
B
