Cooling Performance Data
For ARI Performance Data: See the ARI Directory, Product Data Booklet (PDB), or the product Service Manual.
* Entering Dry Bulb Temperature (°F)
NOTE: Shaded area is ARI rating conditions
All Pressures are PSIG. Low pressures are measured at suction service port, high pressures are measured at liquid valve port.
All temperatures are in °F.
RHE30A2A / BHA30TB002A
Outdoor Ambient Temperature (F°)
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature (°F)
IDB*Airflow 596367715963677159636771596367715963677159636771
Delta T 17 15 11 - 18 15 12 - 18 15 12 - 18 15 12 - 18 15 12 - 16 14 11 -
1150 AMPS 8.3 8.5 8.8 - 8.9 9.2 9.5 - 9.7 9.9 10.3 - 10.4 10.6 11.0 - 11.0 11.3 11.7 - 11.7 11.9 12.3 -
HI PR 133 143 151 - 150 161 170 - 170 183 193 - 194 208 220 - 218 234 248 - 241 259 274 -
LO PR 62 66 72 - 65 70 76 - 68 72 79 - 71 76 83 - 75 80 87 - 77 82 90 -
Delta T 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 17 15 11 -
70 1050 AMPS 8.2 8.4 8.7 - 8.9 9.1 9.4 - 9.6 9.9 10.2 - 10.3 10.5 10.9 - 10.9 11.2 11.6 - 11.6 11.9 12.3 -
HI PR 132 142 150 - 148 160 169 - 169 182 192 - 192 207 219 - 216 233 246 - 239 257 272 -
LO PR 61 65 71 - 65 69 75 - 67 72 78 - 71 75 82 - 74 79 86 - 77 82 89 -
Delta T 19 17 13 - 19 17 13 - 19 17 13 - 19 17 13 - 19 17 13 - 18 16 12 -
950 AMPS 8.1 8.3 8.6 - 8.8 9.0 9.3 - 9.5 9.7 10.0 - 10.1 10.4 10.7 - 10.8 11.0 11.4 - 11.4 11.7 12.1 -
HI PR 130 140 148 - 146 157 166 - 166 179 189 - 189 203 215 - 213 229 242 - 235 253 267 -
LO PR 60 64 70 - 64 68 74 - 66 71 77 - 70 74 81 - 73 78 85 - 76 80 88 -
Delta T201915102019151120191511211915112019151119171410
1150 AMPS 8.4 8.6 8.8 9.2 9.0 9.2 9.5 9.9 9.8 10.0 10.4 10.7 10.5 10.7 11.1 11.5 11.1 11.4 11.8 12.2 11.8 12.1 12.5 12.9
HI PR 135 145 153 160 151 163 172 179 172 185 195 204 196 211 222 232 220 237 250 261 243 262 276 288
LO PR 63 67 73 77 66 70 77 82 69 73 80 85 72 77 84 89 76 80 88 93 78 83 91 97
Delta T211916112119161121191611212016112119161120181510
75 1050 AMPS 8.3 8.5 8.8 9.1 9.0 9.2 9.5 9.8 9.7 10.0 10.3 10.7 10.4 10.6 11.0 11.4 11.0 11.3 11.7 12.1 11.7 12.0 12.4 12.8
HI PR 134 144 152 158 150 161 170 178 171 184 194 202 194 209 221 230 219 235 248 259 241 260 274 286
LO PR 62 66 72 77 66 70 76 81 68 73 79 84 72 76 83 89 75 80 87 93 78 83 90 96
Delta T222017112221171222211712222117122220171221191611
950 AMPS 8.2 8.4 8.6 9.0 8.8 9.0 9.3 9.7 9.6 9.8 10.1 10.5 10.2 10.5 10.8 11.2 10.9 11.1 11.5 11.9 11.5 11.8 12.2 12.6
HI PR 131 141 149 156 147 159 168 175 168 180 191 199 191 206 217 226 215 231 244 255 237 255 270 281
LO PR 61 65 71 75 64 69 75 80 67 71 78 83 70 75 82 87 74 78 86 91 76 81 89 94
Delta T222219152322191523221915232219152222191520201814
1150 AMPS 8.4 8.6 8.9 9.2 9.1 9.3 9.6 10.0 9.9 10.1 10.4 10.8 10.6 10.8 11.2 11.6 11.2 11.5 11.9 12.3 11.9 12.2 12.6 13.0
HI PR 136 146 154 161 153 164 173 181 174 187 197 206 198 213 225 234 222 239 253 263 246 264 279 291
LO PR 63 67 73 78 67 71 77 83 69 74 81 86 73 77 85 90 76 81 89 94 79 84 92 98
Delta T232219162423201624232016242320162322201622211815
80 1050 AMPS 8.4 8.6 8.9 9.2 9.1 9.3 9.6 9.9 9.8 10.1 10.4 10.8 10.5 10.7 11.1 11.5 11.1 11.4 11.8 12.2 11.8 12.1 12.5 13.0
HI PR 135 145 153 160 151 163 172 180 172 185 196 204 196 211 223 233 221 238 251 262 244 262 277 289
LO PR 63 67 73 78 66 70 77 82 69 73 80 85 72 77 84 89 76 81 88 94 78 83 91 97
Delta T252420162524211725242117252421172524211623221915
950 AMPS 8.3 8.5 8.7 9.0 8.9 9.1 9.4 9.8 9.7 9.9 10.2 10.6 10.3 10.6 10.9 11.3 11.0 11.2 11.6 12.0 11.6 11.9 12.3 12.8
HI PR 133 143 151 157 149 160 169 177 169 182 192 201 193 208 219 229 217 234 247 257 240 258 272 284
LO PR 62 66 72 76 65 69 76 81 68 72 79 84 71 76 83 88 75 79 87 92 77 82 90 95
