Amana SRDE528T User Manual

RS5290000 Rev. 0 16 April 1998
Troubleshooting Chart
Symptom Possible Causes Corrective Action
No power to unit. Check for power at outlet. Check
fuse box/circuit breaker for blown
fuse or tripped breaker. Replace or
reset.
Power switch shut off or faulty. Check switch at high voltage board
(electronic models only).
Faulty service cord Check with test light at unit; if no
circuit and current is indicated at
outlet, replace or repair.
Low voltage Check input voltage for proper
voltage. Take appropriate action to
correct voltage supply problem.
Faulty motor or freezer temperature
control
Check all connections are tight and
secure.
Jumper across terminals of control. If
unit runs, replace control.
Faulty timer Check with test light. Replace if
necessary.
Faulty high voltage board
compressor/condenser fan relay
Check relay. Replace if necessary.
Faulty compressor Check compressor motor windings
for opens/shorts.
Perform compressor direct wiring
test.
Replace is necessary.
Unit does not run
Faulty overload Check overload for continuity.
Note:
Ensure
compressor/overload are below
trip temperature before testing.
Replace if necessary.
Excessive door opening Consumer education
Overloading of shelves Consumer education
Warm or hot foods placed in cabinet Consumer education
Refrigerator temperature control set
too warm
Set control to colder setting.
Poor door seal Level cabinet. Adjust hinges.
Replace gasket.
Refrigerator airflow Check damper is opening by
removing grille. With door open,
damper should open. Replace if
faulty.
Turn control knob to colder position.
Check airflow fan. Replace if faulty.
Interior light remains on Check switch. Replace if necessary.
Faulty condenser fan or evaporator
fan
Check fan switch, fan, and wiring.
Replace if necessary
Refrigerator section too warm
Faulty compressor Replace compressor.
Troubleshooting chart on following pages contains symptoms that may be seen in malfunctioning units. Each
symptom is accompanied by one or more possible causes and by a possible remedy or test to determine if
components are working properly.
To avoid risk of electrical shock, personal injury, or death, disconnect electrical power source to unit and discharge
capacitor through a 10,000 ohm resistor before attempting to service, unless test procedures require power to be
connected. Ensure all earthing wires are connected before certifying unit as repaired and/or operational.
!
WARNING
