AMAZON COMMERCIAL 6000 - Page 39

39
EN
VFD
Range Resolution Accuracy
50–700V 0.1V / 1V ±4 % f.m.* ±3digits
DC current
Range Resolution Accuracy
600 μA 0.1 μA
±1 % f.m.* ±3digits
6000 μA 1 μA
60 mA 0.01 m A
600 mA 0.1 mA
6.000 A 0.001 A
±1.5 % f.m.* ±3digits
10 A 0.01 A
10 A: Max. 30seconds with reduced accuracy.
AC current (45 Hz to 1 kHz)
Range Resolution Accuracy
600 μA 0.1 μA
±1.5 % f.m.* ±3digits
6000 μA 1 μA
60 mA 0.01 m A
600 mA 0.1 mA
6.000 A 0.001 A
±2.0 % f.m.* ±3digits
10 A 0.01 A
