• 10 A: Max. 30seconds with reduced
accuracy.
• All AC current ranges are specified from 5%
of range to 100% of range.
• AC current bandwidth:
45 Hz to 1 kHz (sinusoidal);
50/60 Hz (all waves).
Resistance
Range Resolution Accuracy
600Ω 0.1Ω ±1.0 % f.m.* ±2digits
6 kΩ 0.001 kΩ
±0.8 % f.m.* ±2digits60 kΩ 0.01 kΩ
600 kΩ 0.1 kΩ
6 MΩ 0.001 MΩ ±1.2 % f.m.* ±2digits
60 MΩ 0.01 MΩ ±1.0 % f.m.* ±5digits
Test current: <0.35mA.
