Inrush current flow
• In AC current measurement mode, press the
PEAK/INRUSH button (L) to measure the
inrush current value. The INRUSH indicator
(7) appears.
• When the circuit is switched off, clamp on the
circuit being tested for inrush.
• Energize the circuit being tested.
• The product captures the inrush current and
the reading hold on the display (F).
• Press the PEAK/INRUSH button (L) for
2seconds to return to normal operation.
The INRUSH indicator (7) disappears.
CAUTION
Risk of short circuit! Use the
test probe shrouds (R) to avoid accidental short
circuiting if the components or test points are too
near each other.
AC voltage measurement
• Insert the black connector lead (S) into the
negative COM (black) terminal (I) and the red
connector lead(S) into the positive V (red)
terminal (M).
• Set the function switch (K) to the position.
