• In AC voltage measurement mode, press and
hold the MODE/VFD button (H) for 2seconds.
The VFD indicator (10) appears.
• Connect in parallel the test probes (S) to the
circuit or component being measured.
• The stabilized value on (F) is read as the actual
reading.
NOTICE
Press the MODE/VFD button (H) for
2seconds to return to normal operation. The VFD
indicator (10) disappears.
DC voltage measurement
• Insert the black connector lead (S) into the
negative COM (black) terminal (I) and the red
connector lead(S) into the positive V (red)
terminal (M).
• Set the function switch (K) to the position.
• Connect in parallel the test probes (S) to the
component or circuit being measured.
• The stabilized value on the display (F) is read as
the actual reading.
