Assembly
Step 2:
F
E
• Loosen the knurled screw on the leg (F) by turning it counter-clockwise.
• Extend the inner rod to its maximum length, then secure it with the knurled screw.
• Connect the main unit (E) with the rod. Fasten both parts with the knurled screw on the main
unit.
Step 3:
• Unscrew the cap nut in the clockwise direction
from the main unit’s (E) front.
• Unscrew the fixing ring in the counter-clockwise
direction.
E
1
2
