12
EN
Step 4
Wooden window Vinyl-clad window
Q
Q
A
A
• Place the product on the window sill. The bottom rail (S) needs to be
placed against the window sill’s offset.
NOTICE
Ensure the product is tilted 3° to 4° (A = 0.75 - 1" /
1.9-2. cm) downwards with reference to the window sill.
Step 5
E
D
• Fully extend the accordion shutters (E) and (D) so they fit the window
frame.
• Not shown: Use the strips of the weather stripping (C) to close any
leaking points. Cut them to the required size and remove the wax
paper. To improve insulation, stick them on appropriate areas.
