AmazonBasics B07Y2CND3Q User Manual

13
EN
Wooden window
Vinyl-clad window
E
G
L
H
L
E
NOTICE
Ensure the product is tilted 3° to 4° (A = 0.75 - 1” /
1.9-2. cm) downwards with reference to the window sill.
• Wooden windows: Secure the accordion shutters (E) and (D) with the
brackets (G) and the screws (L).
• Vinyl clad windows: Secure the accordion shutters (E) and (D) with
the brackets (H) and the screws (L).
Step 7
D
E
L
F
1 1
2
NOTICE
Before securing the accordion shutters (E) and (D) and
the top rail (F), mark and drill 3 pilot holes in the lower window sash to
prevent it from splitting.
• Close the window sash, so it rests on the top rail (F) and the
accordion shutters (E) and (D).
• Attach the accordion shutters (E) and (D) and the top rail (F) guided
by the pre-drilled holes to the window sash using 3 screws (L).

AmazonBasics B07Y2CND3Q Specifications

General

Brand	AmazonBasics
Model	B07Y2CND3Q
Category	Air Conditioner
Language	English
