EN
6
1. Mark the positions of the screw holes at the desired height (Fig. 2).
2
1.85 in
(4.7 cm)
≥6 in (15 cm)
≤40 in (102 cm)
Cabinet
Outlet
≥52 in (130 cm)
2. Drill the holes. Insert the wall plugs (R) for concrete walls
(Fig. 3).
3
Ø8 mm
1.18"
(3 cm)
1
2
R
3. Mount the wall bracket (S) on the wall with the 2 screws (Q)
using a screwdriver (not included) (Fig. 4).
4
Q
S
4. Hang the appliance on the wall bracket (S) by engaging the
hook with the slot on the main unit (D) (Fig. 5).
5
S
