2 - 4
KE/KG 2/3 b144-03.99
2.8 Technical data
Rotary harrows
2.9 Possibilities of use
of the rotary harrow
The AMAZONE-rotary harrow can be used
- as an individual machine in conjunction
with a tooth packer-, tyre packer, wedge
ring- or support roller (support rollers up
to a working width of 3 m
- as part of a till- and drill combination
with tooth packer-, tyre packer- or sup-
port roller (support rollers up to 3 m
working width) and hitched seed drill
- as part of a till- and drill combination
with tooth packer-, tyre packer- or we-
dge ring roller and a pack top seed drill.
2.10 Range of application
of the rotary harrow
The AMAZONE-rotary harrow can be used
for
- Soil tilling or.
seed bed preparation
after ploughing, usage of a rotary culti-
vator or a deep cultivator or as
- Soil tilling or.
seed bed preparation
without preparatory work on light soil.
AMAZONE-Rotary harrows KE 253 KE 303 KE 403
(see Fig. 2.2) (see Fig. 2.3) (see Fig. 2.4)
working width 2,5 m 3,0 m 4,0 m
number of tools 8 10 14
length of tines 29 cm 29 cm 29 cm
max. working depth 20 cm 20 cm 20 cm
net weight of rotary harrow
without packer roller
740 kg 920 kg 1280 kg
net weight of rotary harrow
with tooth packer roller PW 500
1120 kg 1370 kg 1850 kg
net weight of rotary harrow
with tyre packer-
Pack-Top seed drill RP-AD 2
> 1470 kg > 1775 kg > 2480 kg
t144gb01
