2 - 6
KE/KG 2/3 b144-03.99
2.11 Technical data
Rotary cultivator
2.12 Possibilities of use
of the rotary cultivator
The AMAZONE-rotary cultivator can be
used
- as an individual machine in conjunction
with a tooth packer-, tyre packer, wedge
ring- or support roller (support rollers up
to a working width of 3 m
- as part of a till- and drill combination
with tooth packer-, tyre packer- or sup-
port roller (support rollers up to 3 m
working width) and hitched seed drill
- as an individual machine in conjunction
with a tooth packer-, tyre packer, wedge
ring- or support roller (support rollers up
to a working width of 3 m
- as part of a till- and drill combination
with tooth packer-, tyre packer- or sup-
port roller (support rollers up to 3 m
working width) and hitched seed drill.
The till- and drill combination optimises the
loosening of the soil, recompacting and
precise seeding in one pass.
2.13 Areas of application
of the rotary cultivator
The AMAZONE-rotary cultivator can be
used for
- Seed bed preparation
after ploughing, use of a heavy cultiva-
tor or a deep cultivator
- Seed bed preparation
without prior work
- stubble tilling
without prior work
- pasture tilling without prior work.
AMAZONE-Rotary Cultivator
KG 252 KG 302 KG 402 KG 452 KG 602
(Fig.2.5) (Fig. 2.6) (Fig. 2.7) (Fig. 2.8)
working width 2,5 m 3,0 m 4,0 m 4,5 m 6,0 m
number of rotors 8 10 14 16 20
lenght of tines 29 cm 29 cm 29 cm 29 cm 29 cm
max. working depth 20 cm 20 cm 20 cm 20 cm 20 cm
net weight rotary cultivator
without packer roller
804 kg 1000 kg 1400 kg 1570 kg 2065 kg
net weight of rotary cultivator
with tooth packer roller PW 500
1185 kg 1450 kg 1970 kg 2210 kg 2985 kg
net weight of rotary cultivator
with tyre packer roller-
Pack Top seed drill RP-AD 2
>
1582 kg
>
1910 kg
>
2660 kg
>
3000 kg
>
3920 kg
