Ambient Weather WH31LA User Manual

Version 1.0 ©Copyright 2020, Ambient LLC. All Rights Reserved. Page 2
No Item
1 Alarm (inside the device)
2 Battery cover
3 Sensor contact
4 LED indicator
5 Dip Switches for Multi-channel operation
Figure 1
2. Features
 Detects water every 3 seconds.
 Emits a loud 90 db alarm when triggered.
 High or low sensor sensitivity selectable to meet different requirements.
 View live sensor data online at AmbientWeather.net
 Trigger email alerts, text messages or trigger IFTTT actions.
 Each console supports up to 4 leak detectors.
 Battery power level displayed on AmbientWeather.net
3. Getting Started
The Ambient Weather WH31SM soil moisture sensor includes the following:
QTY Item
1 Leak Detector: 3.5 x 1.5 x 1" (95 x 45 x 22.8 mm)
1
User Manual

Ambient Weather WH31LA Specifications

General

Brand	Ambient Weather
Model	WH31LA
Category	Accessories
Language	English
