Heat Pump Location
And Mounting
✓ It is important that the Ambient Variable Speed Air
Source Heat Pump is installed so that the outside
ambient air is not recirculated through the outdoor coil
✓ Ambient Variable Speed Air Source Heat Pumps are
vertical discharge air flow, meaning fresh air needs to
be available to enter the rear of the heat pump unit
and used air needs to be able to discharge into the
atmosphere
✓ AusGeothermal recommend
Ambient Variable Speed Air Source Heat Pumps should
be installed and mounted on a level concrete slab
using rubber mounting blocks and anchor bolts
✓ Electrical isolator and pipe work to be easily accessible
for service
✓ Electrical and plumbing works to be installed by
licenced and trained technicians only
Important
Failing to comply with above recommendations will
result in Product Warranty becoming void immediately
