A.1 TECHNICAL DATA
(a) General Information:
Model & Heat Input
See Chart Pg (2) for units available
Information all units:
Gas Supply Connection 1/2” NPT Male
Electrical Supply 120V, 1 Phase,
60Hz
Current Rating 1.2 AMP MAX
0.3 Burner
0.9 Fan
Ignition Electronic Program
Start up with Spark
Ignition
OPTIONS: 1. Ambi-Rad Black Bulb
Thermostat.
2. Control Panel with multi-
zone capabilities (not
AGA/CSA certified).
3. Individual Heater Vent to
Exterior.
NOTES:
A. Heater is intended for heating non-
residential indoor spaces and should
only be installed where flammable gases
or vapors are not generally present.
B. Heaters may be suspended either hori-
zontal or at an angle, or may be wall
mounted. See section A3 for clearance
dimensions.
C. The installation must conform with local
building codes or, in the absence of local
codes, with the National Fuel Gas Code,
ANSI Z223.1/NFPA 54 or the Natural
Gas and Propane Installation Code, CSA
B149.1.
D. The unit shall be electrically grounded
accordance with National Electric Code
ANSJJNFPA 70-1987.
E. The heater may be installed in aircraft
hangars when conforming with ANSI/
NFPA 409-1985 and in automotive ga-
rages when conforming with ANSIIN-
FPA 88A (latest edition) for Parking
Structures and ANSIJNFPA 88B (latest
edition) for repair garages. In Canada,
installation code for natural gas burning
appliances and equipment. CAN1-B
149.1 and propane CANIB149.2.
Ensure that minimum clearances will be
maintained to vehicles parked below the
heater.
YWARNING:
Minimum clearance from the heater must be maintained from vehicles parked
below heater. In all situations, clearances to combustibles must be maintained.
Signs should be posted in storage areas to specify maximum stacking height to
maintain required clearance to combustibles. Refer to mounting clearance tables.
YWARNING: Improper installation, adjust-
ment, alteration, service or maintenance can cause
property damage, injury or death. Read the instruc-
tions thoroughly before installing or servicing this
equipment
A. INSTALLATION INSTRUCTIONS
