To Configure the EASYHEAT
If the converter kit (PN 305-0247) has been purchased and installed, follow these
steps to prepare your EASYHEAT to make use of the serial communication option.
Case: You employ the serial port to monitor and control heat-cycle times in your process
Do this... Observe...
 select ►System Options
then 
 press ▲/▼ until...
 select RS485 4 Wire to enable the serial
communications feature; after this step, the port is
activated, but you must take the next steps to
enable serial Start From and Control From
 press ▲/▼ until...
 once this selection has been made, press ▲
 press ► to select Terminal Mode
 select ▲ for addressing (default = 1)
 press ► to modify; 1-32 valid, 0 used for
broadcast; cannot be selected as address
 select ▲ to select baud rate
 press ► to modify; (default = 38400; max
115,200)
 select ▲ to select Start From
 press ► to select RS485 4 Wire
 select ▲ to select Control From
 press ► to select RS485 4 Wire
 complete wiring per previous guide:
Menu Selection
►System Options
Communication
►RS485 4 Wire
Com Protocol
►Terminal Mode
Start From
►RS485 4 Wire
Control From
►RS485 4 Wire
RS485 Baud Rate
►38400
RS485 Address
►1
Serial communication with EASYHEAT takes place when Home zone is displayed;
while in Control mode, the EASYHEAT will not respond to all serial commands.
