AMC IA series User Manual

Specifications
iA120
iA240
iA360
Electrical
Rated output power
120 Watt 240 Watt 360 Watt
Gain control
-12 dB to 0 dB
Input Sensitivity
(at Balanced line)
1,0 ± 0,1Vrms / 10 kOhm
High
-
pass Filter(at
400Hz)
-3dB
Frequency Response
+1,5 / -3 dB at 70Hz - 18kHz
S/N Ratio
Better than 90 dB
T.H.D at 1/2 rated
output, 1kHz
Less than 1,0%
Output Voltage and
Impedance
4Ω / 22V 4Ω / 31V 4Ω / 38V
41Ω / 70V 21Ω / 70V 13.6Ω / 70V
83Ω / 100V 41Ω / 100V 27.8Ω / 100V
Constructions
Cooling
Fan
Operating
temperature/humidity
0° to 40°C at 95% at non-condensing
Dimensions
(width/height/depth)
482 mm x 88 mm x 340 mm
Net weight
11,65kg 13,87kg 15,16kg
Power consumption at
1/8 power
185W 361W 525W
Power requirement
s
AC100V-240V, 50/60Hz and/or DC24V
