ITEM PART NUMBER LOCATION Q'TY
1 90-1181-4 MODULE, MAIN, XIA/A3050a 1
2 30R-1N4148 D601.602.801.802.201.401.708. DIODE SWITCH 1N4148 TAP RoHS HITACHI/ROHM 7
3 30R-1:2Z18V D705.706. ZD 18V 0.5W HZ18-2 TAP RoHS NEC/HITACHI 2
4 30R-BC546B
Q601.602.605.609.610.612.703.
704.705.801.802.805.809.810. 812.
TR NPN HF BC546B TAP RoHS PHILIPS 15
5 30R-BC556B
Q603.604.606.607.608.614.814.
803.804.806.807.808.
TR PNP HF BC556B TAP ROHS PHILIPS 12
6 19R-1181-1*A PCB CAM-1 94V-0 MAIN RoHS A3050/XIA 1
7 12R-2167-2P J301. JACK RCA 2P GOLD-PLATED RoHS 1
8 12R-2167-4P J303.PRE/OUT+MAIN/IN. JACK RCA 4P GOLD-PLATED RoHS 2
9 12R-2167-6P J302. JACK RCA 6P GOLD-PLATED RoHS 1
10 13R-3060-1 J701. JACK HEAD PHONE 7P GOLD-PLATED 1
11 16R-2AS221J R628.828. RSE MO 220R 5% 2W RoHS 2
12 16R-3AN8R2J R627.827. RES MO 8R2 5% 3W RSF3 MK RoHS 2
13 16R-3ANR22J R629.829. RES MO 0.22 5% 3W RSF3 MK RoHS 2
14 16R-5BR22J R623-626.823-826. RES WIREWOUND CEMENT 0.22R/5W R TYPE 5% RoHS 8
15 29R-1110 L601.801. COIL 2.2uH 0.8mmx28.5T RoHS 2
16 29R-4197 VR302.303. VR 50KAx2 RoHS 306d 2
17 17R-5EG109M C701.702. CAP EL 10000uF/50V 20% RoHS D<30x45mm P=10mm SNAP-IN 2
18 30R-1N5402 D701-704. DIODE REQULATOR 1N5402 RoHS 4
19 30R-1:2Z27V ZD 27V 0.5W HZ27-2 TAP RoHS NEC/HITACHI 1
20 30R-2SA1186 Q617.817. TR PNP HF 2SA1186+MICA RoHS 4
21 30R-2SA1358Y Q615.815.702. TR PNP 2SA1358Y P=1.2W RoHS TOSHIBA 3
22 30R-2SC2837 Q616.816.618.818. TR NPN HF 2SC2837+MICA RoHS 4
23 30R-2SC3421Y Q613.813.701.611.811 TR NPN 2SC3421Y P=1.2W RoHS TOSHIBA 5
24 29R-R6V101B VR601.801. VR SEMI-FIX 100R B TYPE RoHS RH0615C12J7XA 2
25 30R-NE5532 IC302. IC NE5532N DUAL OPAMP RoHS PHILIPS 1
26 30R-J309 Q201.401. TR FET J309 N-CH RF AMP RoHS 2
27 30R-NE5534 IC201.401. IC NE5534N/D OPAMP RoHS PHILIPS 2
28 31R-1212-1 S1. SLIDE SWITCH SCM-22BF RoHS 1
29 31R-1241 S3. SW ROTARY SRRZS42N01-EK RoHS RS003-A042 DGc-15K3Q 1
30 31R-1247 S4. SW ROTARY 4P3T RoHS 1
31 11R-5086*A HEAT SINK AL BLK RoHS XIA 1
32 13R-4097 FOR Q616-619.816-819 SILICOON RUBBER SHEET RoHS XIA 8
33 30R-NJM2068D IC303.304. IC NJM2068D OPAMP 8P RoHS 2
34 29R-4212-1 VR301. VR/MOTOR 20KBx2 RoHS RK16312MC076-20KBx2(EK) 1
35 90-1306-3 MODULE, RET/CTL, 3050a/XIA A3050/XIA 1
36 19R-1306 PCB REMOTE CONTROL RoHS 1
37 30R-1N4148 D103.104.105. DIODE SWITCH 1N4148 TAP RoHS HITACHI/ROHM 3
38 30R-2SA1015GR Q102.104-109. TR PNP 2SA1015GR TAP RoHS TOSHIBA 7
39 30R-2SC1815GR Q101.103. TR NPN 2SC1815GR TAP RoHS TOSHIBA 2
40 16R-1AN122J R111. RES MO 1K2 5% 1W RSF1 MK RoHS 1
41 29R-4213 VR102. VR/MOTOR 10KBx2 RoHS 1
42 29R-4214 VR101. VR BAL 5KMNx2 RoHS 1
43 30R-4011 X101. CER-RESONATOR 560KHz RoHS 1
44 30R-5DZ12V D101.102. DIODE ZENER 12V 5W RoHS 2
45 30R-CD74HC4052E U104. IC 74HC4052E DIP RoHS TI 1
46 30R-LM7806A U101. IC REQULATOR LM7806FA 1A RoHS 1
47 30R-LM7906A U102. IC REQULATOR LM7906FA 1A RoHS 1
48 30R-IR-310M IR01. IR RECEIVER MODULE IR-310M 5V 0.7mA Fo=38KHz 940nM RoHS 1
49 30-16C71-50a02A U103. PIC16C71-04/P DIP (PROGRAMMED) 3050a-6.OBJ 1
50 90R-1722 MODULE, RELAY A3050/XIA 1
51 19R-1722 PCB FR4 D-S RELAY RoHS 1
52 30R-1N4002 D1.2. DIODE 1N4002G/GL 1A/100V RoHS 2
53 30R-MPS6724 TR1. TRANSISTOR MPS6724 RoHS 1
54 30R-1:2Z12V D3. ZD 12V 0.5W HZ12A-2 TAP RoHS NEC/HITACHI 1
55 35R-3044-1 RL1. RELAY DC24V OMI-SS-224LM RoHS 1
56 XIAB-COM XIAB COMMON PARTS 1
57 11R-1124B*A COVER TOP (AMC) BLACK RoHS 306d 1
58 11R-6121-1*A CHASSIS, FRONT 306d 1
59 11R-6124*A PLATE BOTTOM RoHS 306d 1
60 11R-6125-3*A CHASSIS, PANEL RIGHT 306d 1
61 11R-8440-3 PANEL REAR A1/EC RoHS XIA 1
62 11R-6126-1 CHASSIS, LEFT 1
63 11R-8629B-1 PANEL FRONT BLACK XIA w430xh72xd23mm 1
64 12R-2115 AC IN/OUT LET PUSH-IN 3P RoHS 0712-PQG 1
65 12R-2195-1 BINDING POST RED/G-PLATE RoHS A2100 2
66 12R-2195-2 BINDING POST BLK/G-PLATE RoHS A2100 2
67 12R-3151 KNOB CONTROL RoHS BLK 306dB 6
PART DESCRIPTION
XIA SERVICE PART LIST - EC, BLACK
