AMC XIA User Manual

4
USBCONNECTOR
TheUSBconnectorisforconnectingto
computer,otherequipmentswithUSB,
LANandsotheInternet.
TheanalogoutputoftheUSBconnector
isinparallelwithauxiliaryinput.
PHONOINPUT
Note:
CDINPUT
TUNERINPUT
AUXILIARYINPUT
TAPEINPUT
PREOUT/MAININ
LOUDSPEAKERS
Thisinputissuitableforbothmoving
magnetandmovingcoilcartridges.For
eithertypeofcartridgetheplugsonyour
turntableleadshouldbeconnectedtothe
phonoinputsocketsontherearpanelof
youramplifier.
Tominimizehumtheturntablelead
shouldbekeptawayfromthemains
wiring,andanyseparateturntableground
leadshouldbeattachedfirmlytothe
earthterminalontherearoftheamplifier.
Aswitchadjacenttothediscinput
socketsallowstheselectionofeitherMM
orMCinput.Facingthebackofthe
amplifier,movetheswitchtotherightfor
usewithMMorhighoutputMCcartridges
andtotheleftforusewithnormal(low
output)MCcartridges.
NeveroperatetheMM/MCselector
switchwiththevolumecontrolturnedup
astheresultantelectricalsurgemay
damageyourloudspeakers.
TheCDinputissuitableforusewithany
CDplayer.ConnectyourCDplayertothe
amplifierusingthephonosocketsmarked
"CD".
TheTunerinputissuitableforusewith
mostAM/FMtuners.Connectyourtuner
totheamplifierusingthephonosockets
marked"Tuner".
TheAuxiliaryinputissuitableforusewith
anyextrasourceprocessingalinelevel
output,perhapsasecondtunerorCD
player, oranadditionaltapeorvideo
recorderwiredforreplayonly.
Theauxiliaryinputisinparallelwiththe
analogoutputoftheUSBconnector.
Thisinputissuitableforusewithmost
cassette,reeltoreelorvideorecorders.
Connectthe"record"leadsofyourtape
recordertothephonosocketsmarked
"Tapeout"ontherearofyouramplifier
usingphono/phonoleads.
Connectthe"playback"leadsofyourtape
recordertothephonosocketsmarked
"Tapein"ontherearofyouramplifier
usingphono/phonoleads.Ifyourtape
machineprocessingDINoutputs,then
DIN/phonoleads,oraDIN/phonoadaptor
canbeused.Ifyouexperiencelevel
matchingproblemswhenusingDIN
connectors,pleaseconsultyourtape
machinemanufacturer.
Normallythepre-amplifierandpower
amplifiersectionsofthisunitare
connectedtogetherviafactory-installed
U-shapedmetaljumpersthatbridgethe
PRE-OUTandMAIN-INjacks.Checkto
besurethattheyarefullyinsertedinto
thejacksandthatnothingistouching
them.
ByswitchingOFFthepowerand
removingthemetaljumpers,youcan
connectasignalprocessorsuchasa
surround-sounddecoderoranelectronic
crossoverinthepathbetweenpreamp
andpoweramp.Connectacablefrom
PRE-OUTtotheprocessor'sinputanda
secondcablefromtheprocessor'soutput
toMAININ.
YourAMCamplifierisdesignedtodrive
loudspeakrswithanominalimpedanceof
4-8ohms.
However,XIAcanonlydrive4ohm
speakersbyswitchingtheimpedance
selectorontherearpaneloftheunitto
the4ohmsetting.
