10 | AMD 4700S 8-CORE DESKTOP KIT USER MANUAL

Figure 2

[Fig. 2] These connectors allow you to connect an ATX power supply. To

connect the ATX power supply, align the power supply cable with the

connector and ﬁrmly press the cable into the connector. If done correctly,

the clip on the power cable should be hooked on the motherboard’s

power connector.

Make sure that all the power cables are securely connected to a proper

ATX power supply to ensure stable operation of the motherboard.

POWER SUPPLY

Power Connectors
