1-2 Specification
Spec Description
Design z Micro u-ATX form factor; size:24.5cm*20.0cm
Chipset
z AMD 760G North Bridge Chipset
z AMD SB710 South Bridge Chipset
CPU Socket
z Support Socket AM2 CPU under 65W and Socket AM2+ CPU under 95W
(optional for Model PA76GM5-LF only)
z Support Socket AM3 CPU under 95W: Phenom II x 4
；
Phenom II x 3
；
Phenom II x2
；
Athlon II x4
；
Athlon II x3
；
Athlon II x2
；
Sempron
z Support HT 3.0
Memory Socket
z 240-pin DDRII Module slot x 2
z Support 2pcs DDRII 400/DDRII 533/DDRII 667/DDRII 800/DDRII 1066
modules expandable to 8GB (optional for PA76GM5-LF Model
）
z 240-pin DDRIII Module slot x 2
z Support 2pcs DDRIII 800/DDRIII 1066/DDRIII 1333 modules expandable to
8GB(optional for PA76GM5D3-LF Model
）
z Dual channel supported
Expansion Slot
z 1pcs PCI-Express 2.0 x16 by 16 lane
z 2 pcs 32-bit PCI slots
Integrate IDE
and Serial ATA2
RAID
z One IDE controllers support PCI Bus Mastering, ATA PIO/DMA and the
ULTRA DMA 33/66/100/133 functions that deliver the data transfer rate up to
133 MB/s for two IDE Devices and for six Serial ATA2 ports providing 300
MB/sec data transfer rate with RAID 0, 1, 10, JBOD functions
Gigabit LAN
z Integrated PCI-E 10/100 LAN chip
z Support Fast Ethernet LAN function of providing 10Mb/100Mbs data transfer
rate
6 CH-Audio
z Realtek ALC662 HD Audio 6-channel Audio Codec integrated
z Audio driver and utility included
BIOS z AMI 8MB DIP Flash ROM BIOS
Multi I/O
z PS/2 keyboard and PS/2 mouse connectors
z DVI Connector x1
z VGA Connector x1
z USB 2.0 port x4 and header x2
z RJ-45 LAN Connector x1
z Audio connector x1(Line-in, Line-out, MIC)
z Hard disk driver connector x1/ SATA connector x 6
z Serial Port header x1
z CDIN header x1
z Audio header x1
1-3 Item Checklist
5
AMD760G platform processor chipset based motherboard
5
CD for motherboard utilities
5
User’s manual
5
I/O back panel shield
5
Hard disk cable
