AMD 760G - Page 8

5
5
Diagram is for PA76GM5D3-LF
Realtek Megabi
t
LAN Chip
ATA 133 IDE
Conn. (IDE1)
CPU Socket
ATX Power Conn.
PCI Slots
PS2 KB
/MS Port
ATX 12V Power Connecto
r
Realtek ALC662
Audio Decode
CDIN Header
PWRLED1 Header
USB Heade
r
Front Panel
Audio Header
KB/USB Power On (JP1)
CPU FAN
SYSFAN2
DVI
Connector
COM1 Header
USB
Connector
AMD SB710 Chipset
VGA
Connector
DDRIII Slot x 2
8 MBit DIP Flash ROM BIOS
Audio
Connecto
r
RJ-45 over
USB Connecto
r
Speak Heade
r
Front Panel Header
Serial-ATAII Connecto
r
s
SATA1, 2, 3,4,5,6
SYSFAN1
AMD 760G Chipset
JBAT
PCI Express
X 16 by 16-lane
