Chapter 1
Introduction of Motherboards
1-1 Motherboard Specification
Spec Description
Design
z Micro-ATX Form Factor
z Size: 24.5 x 19.0 cm
Chipset
z AMD™ A75 FCH (Hudson D3) Chipset (Optional for A75M series)
z AMD™ A55 FCH (Hudson D2) Chipset (Optional for A55M series)
CPU Socket
z AMD™ Socket FM1
：
z Support AMD™ A- & E2- “Lynx” Series APU
* For more detailed CPU support information please visit our website
Memory Slot
z 240-pin DDRIII Module slot x 2
z Support 2pcs of DDRIII 1066/1333/1600/1866 memory modules
expandable to 8GB
z Dual channel supported
Expansion
Slot
z 1pcs * PCI-Express 2.0 x16 by 16 lane slot
z 1pcs * PCI-Express 2.0 x1 slot
z 1pcs * 32-bit PCI slot
z
Storage
z 4 * SATAIII 6Gb/s connectors (Optional for A75M series)
z 4* SATAII 3Gb/s connectors (Optional for A55M series)
LAN Chip
z Integrated with PCI-E megabit LAN chip providing 10/100Mbps data
transfer rate
z Support Fast Ethernet LAN function
HD Audio Chip
z 6-channel HD Audio Audio Codec integrated
z Audio driver and utility included
BIOS
z 16MB Flash ROM BIOS
Multi I/O
z PS/2 keyboard connector x1
z PS/2 mouse connector x1
z VGA connector x1
z DVI connector x1
z HDMI connector x 1
z USB 2.0 port x 2 + USB 3.0 port x 2(Optional for A75M series)
z USB 3.0 header x1 (Optional for A75M series)
z USB 2.0 port x 4 (Optional for A55M series)
z USB 2.0 header x 2
z RJ-45 LAN connector x1
z Audio connector x1
z Front panel audio header x1
z HDMI-SPDIF header x1
z Speaker header x1
z PWR LED header x1
z Front panel header x1
Item Checklist
z Motherboard
z DVD for motherboard utilities
z User’s Manual
z Hard Disk Cable
z
Back Shied
