4. Remove any unneeded graphics cards from the computer.
Warning:
Some graphics cards can get hot while operating. Wait approximately five
minutes after turning off the computer before touching the card.
5. Locate the PCIe slots on the motherboard. If necessary, also remove the
corresponding back panel cover.
6. Align the new graphics card in the secondary PCIe slot next to the existing
graphics card and press firmly until the card is fully seated.
Tip: For optimal performance in a dual-GPU AMD CrossFire configuration,
make sure that each AMD Radeon R7 240/R7 250 graphics card is separated by
at least one empty expansion slot.
7. If needed, connect the power supply to the cards.
Tip: The location of power connections may vary between models. They can
be located on either the side or back of the card.
12 AMD CrossFire™ Technology
AMD Radeon™ R7 240/R7 250 Graphics © 2014 Advanced Micro Devices, Inc.

AMD R7 250 Specifications

General

GPU Architecture	GCN 1.0
GPU Codename	Oland
Process Size	28 nm
Shader Units	384
Shader Model	5.0
Power Consumption	65W
Outputs	DVI, HDMI, DisplayPort
Max. Resolution	4096x2160
Memory Size	1 GB / 2 GB
Memory Type	GDDR5
Memory Bus	128 bit
