Ameristar M4THM1530A - Dimensional Diagrams

Dimensional Diagrams
18K Units
24K-30K Units
35 1/8
37 1/4
27 9/16
15 10/16
13 7/16
22
14 1/2
35 7/16
32
/1 32 2
14 7/8
12 7/16
13 1/2
21 11/16
Unit:inch
Unit:inch
The dimensions in these drawings
are rounded according to standard
measurement.
The dimensions in these drawings
are rounded according to standard
measurement.
33
15 Series Multi-Split
