Before You Start
Cam Lock Fastening System
3
ameriwoodhome.com
P
P
P
P
P
This Cam Lock Fastening System will be used throughout the assembly process.
Read through each step carefully and follow the proper order
Separate and count all your parts and hardware
Give yourself enough room for the assembly process
Have the following tools: Flat Head Screwdriver, #2 Phillips Head
Screwdriver and Hammer
Cau! on: If using a power drill or power screwdriver for screwing,
please be aware to slow down and stop when screw is ! ght.
Failure to do so may result in stripping the screw.
Q
u
i
c
k
T
i
p
A
s
s
e
m
b
l
y
1
3
2
4
