STEP10
IMPORTANT! THEBACKPANEL ISASTRUCTURALPARTOFTHISUNIT
ANDMUSTBEINSTALLEDPROPERLY.
Attachedthebackpanelasshownnailingstraightintotherawedges.
Assurethattheunitissquare.Distancefromcornertocornermustbeequalasshown.
(x44)
#A21110
7
Besurethebackpanelisflush
withthebottomedgeofthe
bottom(E).
Assurethattheunitissquare.Distance
fromcornertocornermustbeequalas
shown.
7
K
unfinished
surface
