Ameriwood HOME Aldridge 8637337EBL - Page 7

7
ameriwoodhome.com
PartList
ActualSize
NotActualSize
3
4
9
(x12)
#A22700
cam lock
(x12)
#A22710
cam bolt
(x14)
#A21660
wood dowel
(x4)
#A23030
confirmat screw
(x32)
#A21110
nail
(x4)
#A80250
shelfsupport
Notethatyourunitmaycontainextrahardware
1
2
6
8
5
(x2)
#A31000
single mag catch
5a
5b
(x16)
#A12120
#8x7/16"phpn
7
(x4)
#A17400
5/8"bolt
(x18)
#A22760
quickloc
10
11
(x2)
#A52697
handle
5c
5d
