STEP
16
9
Tube
You
9.1 Attach (1) to (A) as illustrated. Do NOT over tighten.
9.2 Attach (L) to (A) with (2) & (4) as illustrated.
× 8
1
Ø6 x 25mm
× 4
2
Ø8 x 30 mm
A
A
L
2
4
1
× 4
Ø4 x 40 mm
4
