STEP
17
10
Tube
You
10.1 Attach (A) to (D), (E) & (K) with (2) & (9) as illustrated.
× 6
2
Ø8 x 30 mm
× 8
9
Ø15 x 12mm
Assembly
UNLOCK
LOCK
Tip
Quick
Proper orientation of CAM LOCK
D
E
A
2
9
K
K
