ameriwoodhome.com
STEP
19
12
Tube
You
12.1 Attach (O) to (B) with (2) & (4) as illustrated.
× 2
2
Ø8 x 30 mm
4
B
O
× 3
Ø4 x 40 mm
4
2
(Unfinished)
