ameriwoodhome.com
STEP
20
13
Tube
You
13.1 Attach (N) to (B) with (2) & (4) as illustrated.
× 4
2
Ø8 x 30 mm
× 4
Ø4 x 40 mm
4
4
N
2
B
(Unfinished)
