STEP
23
16
16.1 Attach (S), (T) & (U) to (R) with (2) & (9) as illustrated.
16.2 Attach (Q) to (S), (T) & (U) with (2) & (9) as illustrated.
× 8
2
Ø8 x 30 mm
× 8
9
Ø15 x 12mm
R
T
S
U
U
U
U
T
S
Q
9
2
2
Assembly
UNLOCK
LOCK
Tip
Quick
Proper orientation of CAM LOCK
