STEP
24
17
× 12
2
Ø8 x 30 mm
× 14
9
Ø15 x 12mm
Assembly
UNLOCK
LOCK
Tip
Quick
Proper orientation of CAM LOCK
R
Q
U
U
B
S
T
9
2
J
J
17.1 Place the frame from previous assembly step to (B) as illustrated.
17.2 Attach (Q), (R), (S), (T) and (U) to (B) with (2) & (9) as illustrated.
Tip: Insert and tighten the cam lock one by one when all positions are corrected.
