STEP
31
24
Handling with 2 person
To adjust the fireplace horizontal depth:
Loosen screws on (F), (G) & (B), adjust the position of the fireplace to align with front side rail (H),
tighten screws gradually and evenly when all positions are corrected.
F
Screw
Screw
B
G
Screw
To adjust the fireplace sideways:
Loosen pre-installed bolts at (F) & (G) of fireplace, align the fireplace to the center, tighten bolts
gradually and evenly when all positions are corrected.
F
G
Pre-installled
bolt
Pre-installed
bolt
CAUTION:
- The assembly need 2 person to handle.
- To avoid the fireplace moving during
the adjustment, have one person hold
the fireplace in place while the other
person tighten the bolts and screws
gradually and evenly.
H
H
Fireplace Location Adjustment Instruction
