73050-OLV Division 2 Sample System
Dryer Valve
Micron Filter
3050
Back Press. Reg.
DRYER
Liquid Trap
CONTAMINANT TRAP
SAMPLE
INLET
BYPASS
EXHAUST
SAMPLE
EXHAUST
Bypass Valve
Sample Line - (Heat Traced
with Thermo Switch)
Figure 1: Sample system  ow diagram
