10 123199 04
Caution…
The well and the insertion tube must be clean before
use.
The insertion tube must never be forced into the well.
The well could be damaged as a result, and the
insertion tube may get stuck.
Do not pour any form of liquids into the well. It might
damage the well or cause a hazard.
5. If the design of the sensor permits it, use an insulation tube
(pos. 2) and insulation (pos. 3) for the best results. These
should be mounted as shown in fig. 1.
6. Place the sensor (pos. 1) in the insertion tube (pos. 4) as
shown in fig. 1.
7. In order to protect the sensor and its connections it is
recommended to use a heat protection shield (104216) at
high temperatures.
