RS232 COMMUNICATION INTERFACE
Type of connection IEC320
ENVIRONMENT
Ambient operating temperature range 0-40°C / 32-104°F
Storage temperature range -20-50°C / -4-122°F
Humidity range 0-90% RH.
Protection class IP10
READOUT SPECIFICATIONS
Resolution 0.1°C / 0.1°F
Temperature units °C / °F
THERMAL SPECIFICATIONS ITC-155 A
Maximum temperature 155°C / 311°F
Minimum temperature -39°C / -38.2°F @ ambient temperature 0°C /
32°F
-23°C / -9.4°F @ ambient temperature 23°C /
73.4°F
-10°C / 14°F @ ambient temperature 40°C /
104°F
Well specifications 40 mm / 1.57 inch axial homogeneity :
0.10°C / 0.18°F @155°C / 311°F
0.05°C / 0.09°F @-20°C / -4°F
50 mm / 1.97 inch axial homogeneity :
0.10°C / 0.18°F @155°C / 311°F
0.10°C / 0.18°F @-20°C / -4°F
60 mm / 2.36 inch axial homogeneity :
0.20°C / 0.36°F @155°C / 311°F
0.15°C / 0.27°F @-20°C / -4°F
70 mm / 2.76 inch axial homogeneity :
0.40°C / 0.72°F @155°C / 311°F
0.35°C / 0.63°F @-20°C / -4°F
